A powerful, affordable solution designed for versatility and precision. With a compact and lightweight build, it's perfect for integration into various systems without compromising on performance. Featuring a high-resolution 1280x1024 display, this core captures crystal-clear thermal images. Its low NETD and MRTD ensure exceptional sensitivity and clarity, even in demanding environments. Combining cutting-edge technology with affordability, it delivers top-tier thermal imaging for a range of applications, from security to industrial use.
HD Resolution
3KM HD Micro Thermal Camera Core boasts an impressive 1280x1024 HD resolution, delivering exceptional image clarity and fine detail. This high resolution ensures that even the smallest temperature variations are captured with precision, allowing users to see the thermal environment in remarkable detail.
All-Condition Performance
The HD Micro Thermal Camera Core is engineered to perform reliably in all conditions, whether you're operating in extreme heat, cold, or low-visibility environments. Its advanced thermal imaging technology ensures clear and precise performance.
Feature
- Sensor: UFPA (VOx)
- Resolution: 1280x1024
- Frame Rate: 30Hz
- Digital Zoom: 1-4x
- MRTD: ≤300 mK
- NETD: ≤30 mK
Product Parameters
|
Product Parameters |
|
|
Item |
HD Micro Thermal Core |
|
Detector |
|
|
Sensor |
UFPA (VOx) |
|
Resolution |
1280(H)×1024(V) |
|
Pixel Pitch |
12 μm |
|
Spectral Range |
8 μm～14 μm |
|
Frame Rate |
50Hz |
|
MRTD |
≤300 mK |
|
NETD |
≤30 mK |
|
Image Processing |
|
|
Bad Pixel Correction |
Yes |
|
Non-uniformity Correction |
Yes |
|
Digital Detail Enhancement |
Yes |
|
Functions |
|
|
Digital Zoom |
1~4X |
|
Image Calibration |
Manual /Automatic (with shutter) |
|
Brightness / Contrast Adjustment |
Manual /Automatic |
|
Polarity |
White Hot / Black Hot |
|
Power |
|
|
Supply Voltage |
DC 12V(9V~15V) |
|
Power Dissipation |
≤3.2W |
|
Reverse Connection Protection |
Yes |
|
Interface |
|
|
Video Output Interface |
SDI / MIPI |
|
Communication Interface |
RS 422 / RS 232 |
|
Environmental Parameter |
|
|
Operating temperature |
-40°C ~ +60°C |
|
Storage temperature |
-45°C ~ +70°C |
|
Physical Characteristics |
|
|
Weight |
≤85g |
|
Dimensions (without lens) |
38mm × 38mm × 35mm |
