Thermal Imaging
Your Professional Thermal Imaging Supplier
3KM Optoelectronics is a national high-tech enterprise focusing on the research and development and technical application of special light sources. At present, our laser lighting products include infrared laser illumination module in the 400-1600nm band, white laser light, and other visible laser lighting module.
Parameter
|
Product Parameters |
|
|
Item |
HD Micro Thermal Core |
|
Detector |
|
|
Sensor |
UFPA (VOx) |
|
Resolution |
1280(H)×1024(V) |
|
Pixel Pitch |
12 μm |
|
Spectral Range |
8 μm～14 μm |
|
Frame Rate |
50Hz |
|
MRTD |
≤300 mK |
|
NETD |
≤30 mK |
|
Image Processing |
|
|
Bad Pixel Correction |
Yes |
|
Non-uniformity Correction |
Yes |
|
Digital Detail Enhancement |
Yes |
|
Functions |
|
|
Digital Zoom |
1~4X |
|
Image Calibration |
Manual /Automatic (with shutter) |
|
Brightness / Contrast Adjustment |
Manual /Automatic |
|
Polarity |
White Hot / Black Hot |
|
Power |
|
|
Supply Voltage |
DC 12V(9V~15V) |
|
Power Dissipation |
≤3.2W |
|
Reverse Connection Protection |
Yes |
|
Interface |
|
|
Video Output Interface |
SDI / MIPI |
|
Communication Interface |
RS 422 / RS 232 |
|
Environmental Parameter |
|
|
Operating temperature |
-40°C ~ +60°C |
|
Storage temperature |
-45°C ~ +70°C |
|
Physical Characteristics |
|
|
Weight |
≤85g |
|
Dimensions (without lens) |
38mm × 38mm × 35mm |
Features of Thermal Imaging
See through the total darkness - The infrared thermal imaging can present a clear and vivid image when the light condition is poor or even in total darkness. It can work through day and night.
Identification under camouflage - It can detect hidden thermal targets under camouflage, through grass, leaves or bushes.
Long range detection - In the case of zero illumination, it can clearly identify people or objects within a range of several hundred meters, or detect vehicles/ships from several kilometers and even aircraft in hundreds of kilometers away.
Heat Distribution - The heat distribution of the target surface can be reflected by using the difference of infrared thermal radiation among the target, background and each part of the target.
Temperature Measurement - According to the corresponding relationship between the infrared energy radiation value of the target and the temperature, the absolute temperature value of the target is measured.
Fearless of interference - Infrared thermal imaging could penetrate rain, smoke, fog, light glare and work in harsh weather conditions.
Good Concealment - It doesn't need to send infrared ray to the target actively, so it is not easy to be found and keep oneself concealed.
Application of Thermal Imaging
Border Patrol
Stationary and portable thermal imaging units are used for detecting evidence of border trespassing, searching and detaining violators in the night and day.
Search and Rescue Operations
Lifeguards and rescue teams use thermal imaging units to search for the injured during catastrophic events. Frequently thermal imagers are used in search and rescue operations when the search has to be conducted in the nighttime. Thanks to the ability of thermal imagers “to see” through the smoke they are also widely used for searching and orienting in conditions of dense smoke.
Security and Law Enforcement
Thermal imaging cameras help to detect criminals in pitch black conditions, without drawing attention and do not require additional lighting, winning valuable time before the law enforcement team arrives.
Non-contact Testing
Thermal imaging is one method of non-contact control where the parameters and quality of products can be evaluated without direct physical contact.
Shipping Methods: We offer a variety of shipping options, including sea freight, air freight, railway transportation, and international express delivery, to meet the diverse needs of our customers.
Estimated Delivery Time: We will provide you with the estimated delivery time for your order, which will be clearly stated in the formal order to ensure your rights are protected, allowing you to arrange for the receipt of your goods in a timely manner.
Order Tracking: We provide order tracking services, allowing you to stay informed about the current status and expected arrival time of your order. Detailed inspection information and shipping manifests, including photos and videos, are provided to ensure the security of your transactions.
Certificates
FAQ
As one of the most professional thermal imaging manufacturers and suppliers in China, we're featured by high quality customized service and ODM service. Welcome to buy durable thermal imaging from our factory. Contact us for quotation and free sample.
