The desert-spec laser beacon is a robust, long-range signaling device engineered to serve in arid, desert environments where conventional signaling methods may fail. Features 3KM's advanced laser technology, it provides a focusable, visible beam over vast distances. The light beam emitted during the day can reaches up to 500 meters and 1,000 meters at night. Available in red, blue, green, and white, it is ideal for marking locations, signaling, or designating targets in expansive, open terrains.
- Wind-resistant, sand-proof, waterproof
- Automatic cleaning.
- Strobe mode.
- Laser system: service life up to 20,000 hours.
- Solar power generation & energy storage system: Service life up to 10 years.
Desert-spec laser beacon system
Robust Engineering
Solar laser beacon system is designed to endure the harsh conditions in arid and desert environments. Features wind-resistant, sand-proof, waterproof design, it also provides automated cleaning and maintenance functions.
Solar Powered
Integrated efficiency solar panels, which has a service life of 10 years, the solar laser beacon system provide sustained functionality in desert without the need for regular battery replacements or fuel resupply.
Laser beacon light the way of life in the Nafud Desert of Saudi Arabia
I. Notes
- This IR laser illuminator is classified as a Class IV non-visible light laser. While the laser is on, staring back at or observing the laser with an optical instrument is strictly prohibited.
- While the IR laser illuminator is on, flammable objects are strictly prohibited within 100cm in front of the lens to prevent fires.
- The IR laser illuminator should be installed where people cannot see it directly, or at a safe distance where people can see it directly. Manufacturers should choose the laser radiation power according to its actual application environment to avoid hurting people's eyes.
- Manufacturers using this IR laser illuminator should put warning labels for laser radiation.
- Please contact our qualified maintenance personnel for service when a device fault occurs. The warranty will expire if the device is disassembled by anyone else.
I. Technical Parameters
|
Parameters |
Values and Description |
|
Product ID |
K10070008 |
|
Model |
VL-525-500-BR |
|
Effective Range |
≥1000m (night), ≥500m (day) |
|
Center Laser Wavelength |
525nm±10nm(@25℃) |
|
Total Power |
≤60W |
|
Laser Output Power |
≥6.5W |
|
Illumination Angle |
0.1°~10° (Continuous zoom) |
|
Spot Diameter |
φ0.9m(@0.1°, @500m) |
|
Laser Safety Distance |
≥150m(@0.1°,@Pomax) |
|
Operating Voltage |
DC33V±10% |
|
Communication Interface |
RS-485/UART portTTL(Default: 9600bps) |
|
Communication Protocol |
Pelco_D |
|
Operating Temperature |
-35℃～+55℃ |
|
Storage Temperature |
-50℃～+100℃ |
|
Profile Dimensions |
L*W*H：392.5*153*139mm |
|
Weight |
2.5kg |
Note: products and parameters are subject to the quotation scheme and may change without prior notice.
II. Overall Dimensions
III. Interface Definition
