Reach unmatched distances with LRF-0816B SWIR laser rangefinder module, designed for extreme-range accuracy in the most challenging conditions. Leveraging shortwave infrared technology, this module delivers precise distance measurements up to 12,000 meters, excelling in fog, smoke, and low-light environments where conventional systems fall short.
Despite its exceptional range, the module remains lightweight and compact, ensuring seamless integration into advanced targeting, surveillance, and defense systems without adding unnecessary bulk. As an OEM/ODM solution, it can be fully customized to meet your exact requirements.
Characteristic
|
Range |
Accuracy |
Wavelength |
Weight |
Dimension |
|
≥12000m |
±2 m |
1535±5nm |
≤175g |
65×48×32 mm |
Specifications
|
Item |
Details |
|
|
Wavelength |
1.54μm±0.02μm |
|
|
Eye Safety |
Class I (IEC 60825-1) |
|
|
Divergence Angle |
≤0.35 mrad |
|
|
Receiving Field of View (FOV) |
~2.0 mrad |
|
|
Launch Lens Diameter |
Φ12mm |
|
|
Receiver Lens Diameter |
Φ40mm |
|
|
Measuring Range Reflectance 30% Visibility ≥ 8km |
Large Target(4m×6m) |
≥12000 m |
|
Car (2.3m×2.3m) |
≥ 8200 m |
|
|
People (0.5m×1.7m) |
≥ 3000 m |
|
|
Drones (0.2m×0.3m) |
≥1500 m |
|
|
Minimum Range |
50 m |
|
|
Ranging Frequency |
0.5~10Hz |
|
|
Ranging Accuracy |
±2 m |
|
|
Range Resolution |
≤30 m |
|
|
Precision Rate |
≥98% |
|
|
False Alarm Rate |
≤1% |
|
|
Number of multi-target detections |
Up to 3 targets |
|
|
Electrical Interface |
molex- 532610771 |
|
|
Supply Voltage |
DC12 V |
|
|
Standby power consumption |
≤1.2W |
|
|
Average power consumption |
≤2 W |
|
|
Peak Power Consumption |
≤3W@10Hz |
|
|
Weight |
≤175g |
|
|
Dimension (L×W×H) |
65mm×48mm×32 mm |
|
|
Operating Temperature |
-40～+70 ℃ |
|
|
Storage Temperature |
-55～+75 ℃ |
|
|
Impact Resistance |
1200 g/1 ms(GJB150.16A-2009) |
|
|
Anti-vibration |
5～50～5 Hz,1 Octave range /min,2.5 g |
|
|
Ranging Logic |
First and last target, multi-target ranging, distance selectivity |
|
|
Activation Time |
≤950 ms |
|
|
Data Interface |
TTL |
|
|
Electrical isolation |
Isolation of power ground, communication ground and structure ground |
|
|
Reliability |
MTBF ≥ 1500h |
|
|
Optical axis stability |
≤0.05 mrad |
|
|
Non-parallelism between optical axis and mounting surface |
≤0.5 mrad |
|
|
IP Rating |
IP67 |
|
|
ESD Class |
(Lens position) Contact discharge 6kV Air discharge 8kV |
|
|
Electromagnetic Compatibility (EMC) |
CE/FCC Certification |
|
|
Eco-friendly |
RoHS2.0 |
|
