Achieve precise long-range measurements with LRF-0012A laser rangefinder module, built for effortless integration into optical and targeting systems. Delivering fast and accurate readings up to 1,200 meters, this module enhances performance in hunting, defense, surveying, and industrial applications.
Designed for seamless adaptability, it offers consistent accuracy and rapid response, ensuring reliability in challenging conditions.
Characteristic
|
Range |
Accuracy |
Wavelength |
Weight |
Dimension |
|
≥5~1200m |
±1m |
905nm |
≤22g |
23mm×40mm |
Specifications
|
Item |
LRF-0012A |
|
Wavelength |
905nm |
|
Eye Safety |
Class 3R(IEC 60825-1) |
|
Divergence Angle |
≤10mrad |
|
Display accuracy |
0.1m |
|
Launch Lens Diameter |
Φ6.6mm |
|
Receiver Lens Diameter |
Φ18mm |
|
Measuring Range (3m × 3m Target) |
≥5~1200m |
|
Ranging Accuracy |
10≤L≤100m: ±1m L＞100m:±(1+L*0.4%) m |
|
Display Accuracy |
0.1m |
|
Ranging Frequency |
1~3Hz |
|
Accurately measuring probability |
≥98% (10-400) m; ≥80% (401-1200) m |
|
Start Time |
≤500ms |
|
Data Interface |
UART (TTL_3.3V) |
|
Supply Voltage |
3.3+/-0.1V |
|
Standby Power Consumption |
≤1mW |
|
Operating Power Consumption |
≤1.5W |
|
Weight |
≤22g |
|
Dimension |
Ф23mm×40mm |
|
Operating Temperature |
-20~＋55℃ |
|
Storage Temperature |
-55~＋65℃ |
|
Impact Resistance |
1200g,1ms |
|
Anti-vibration |
800g/ms (10 times/s in the optical axis direction) |
|
Dependability |
MTBF≥1500 h |
|
IP Rating |
IP67(Head piece) |
|
ESD Class |
(Lens position) Contact discharge 6kV Air discharge 8kV |
|
Electromagnetic Compatibility (EMC) |
CE/FCC Certification |
|
Environmental Standard |
RoHS2.0 |
